Laser cut in any grade - 304, 316, 321, 430
Stainless steel laser cut-tech is the second most common application. It is more costly than carbon steel. Despite this, it is commonly used in numerous industries for decorative coating treatments when in combination with the corrosion resistance.
Maximum Plate Size
1500x3000mm
Minimum Part Size
Minuscules (per material thickness)
Maximum Thickness
12 mm
Minimum Thickness
<0.4mm
Cutting Tolerance
less than 3mm (with - +/-0.15mm)
3-6mm (with - +/-0.2mm)
8-12mm (with - +/-0.25mm)
>12 mm (with - +/-0.5mm)
Endresults for Thermal Cutting
In case of thin materials, the cutting edges are smooth and even. The edges' quality slightly decreases as thickness increases.
Sheet Dimensions
1000x2000 mm 1250x2500 mm 1500x3000 mm
Applications
It can be applied on to any surface that requires treatment to certain degree of corrosion resistance and/or a decorative surface coating. It is used in the manufacture of equipment, interalia, as used in airports, hospitals, foods, shipping and almost many other related industrial sectors.
